NASA has selected Masten Space Systems of Mojave, Calif., to deliver and operate eight payloads—with nine science and technology instruments—to the Moon’s South Pole in 2022 to help lay the foundation for human expeditions to the lunar surface beginning in 2024. The payloads, which include instruments to assess the composition of the lunar surface, test precision landing technologies, and evaluate the radiation on the Moon, are being delivered under NASA’s Commercial Lunar Payload Services (CLPS) initiative as part of the agency’s Artemis program. As the country and the world face the challenges of the COVID-19 pandemic, NASA is leveraging virtual presence and communications tools to safely make progress on these lunar exploration activities and to award this lunar surface delivery as it was scheduled prior to the pandemic.

“Under our Artemis program, we are going to the Moon with all of America,” said Jim Bridenstine, NASA administrator. “Commercial industry is critical to making our vision for lunar exploration a reality. The science and technology we are sending to the lunar surface ahead of our crewed missions will help us understand the lunar environment better than we ever have before. These CLPS deliveries are on the cutting edge of our work to do great science and support human exploration of the Moon. I’m happy to welcome another of our innovative companies to the group that is ready to start taking our payloads to the Moon as soon as possible.”



Key Instrumentation

The $75.9 million award includes end-to-end services for delivery of the instruments, including payload integration, launch from Earth, landing on the Moon’s surface, and operation for at least 12 days. Masten Space Systems will land these payloads on the Moon with its XL-1 lander.

“The Moon provides great scientific value, and these payloads will advance what we know and help define and improve the science astronauts can do,” said Thomas Zurbuchen, associate administrator of NASA’s Science Mission Directorate (SMD). “Our commercial Moon delivery efforts are seeking to demonstrate how frequent and affordable access to the lunar surface benefits both science and exploration.”

The payloads that will be delivered have been developed predominantly from the two recent NASA Provided Lunar Payloads (NPLP) and Lunar Surface Instrument and Technology Payloads (LSITP) solicitations. The nine instruments to be delivered include:

  • Lunar compact infrared imaging system (L-CIRiS), which will will deploy a radiometer to explore the Moon’s surface composition, map its surface temperature distribution, and demonstrate the instrument’s feasibility for future lunar resource utilization activities.
  • Linear energy transfer spectrometer (LETS), a sensor that will measure the radiation environment on the Moon’s surface. The payload also is being flown on a CLPS flight to the Moon in 2021.
  • Heimdall, a flexible camera system for conducting lunar science on commercial vehicles. This innovation includes a single digital video recorder and four cameras: a wide-angle descent imager, a narrow-angle regolith imager, and two wide-angle panoramic imagers. This camera system is intended to model the properties of the Moon’s regolith (the soil and other material that make up the top layer of the lunar surface) and characterize and map geologic features. Other goals for this instrument include characterizing potential landing or trafficability hazards.
  • MoonRanger, a small robotic rover that weighs less than 30 lbs and will demonstrate communications and mapping technologies. It will demonstrate the ability to move quickly across long distances on the lunar surface with autonomous navigation and without the ability to communicate with Earth in real time. It is a technology that could enable exploration of destinations that are far from lunar landing sites. The MoonRanger will carry the Neutron Spectrometer System, which will measure the concentration of hydrogen in the Moon’s regolith—a possible indication of the existence of buried water.
  • Mass spectrometer observing lunar operations (MSolo), a device to measure potentially accessible resources on the Moon’s surface. It will identify gases coming off a lander during touchdown on the lunar surface to help scientists understand what elements are coming from the lunar surface and which ones are introduced by a lander itself.
  • Near-infrared volatile spectrometer system (NIRVSS), a tool to measure surface composition and temperature. The instrument will characterize the variability of the lunar soils and detect volatiles such as methane, carbon dioxide, ammonia, and water.
  • Laser retroreflector array (LRA), a series of eight small mirrors to measure distance and support landing accuracy. It requires no power or communications from the lander and can be detected by future spacecraft orbiting or landing on the Moon.
  • Sample acquisition, morphology filtering, and probing of lunar regolith (SAMPLR), a robotic arm that will collect samples of lunar regolith and demonstrate the use of a robotic scoop that can filter and isolate particles of different sizes. The sampling technology makes use of a flight spare from the Mars Exploration Rover project.



Additional Payload Deliveries

NASA has contracted with 14 American companies to deliver science and technology to the lunar surface through competed task orders. The agency plans to issue at least two such task orders per year through which the companies can propose to take payloads to the Moon. Under the Artemis program, early commercial deliveries of payloads to the lunar surface missions enable NASA to perform science experiments, test technologies, and demonstrate capabilities to further explore the Moon and prepare for human missions.

“I am very pleased to award our next delivery service task order to Masten Space Systems,” said Steven Clarke, deputy associate administrator for exploration in SMD. “With the first delivery in 2022, we are continuing to execute our strategy of providing two delivery opportunities per year of science investigations and technology demonstration payloads to the lunar surface.”

For more information, visit www.nasa.gov/clps, www.nasa.gov/artemis and www.masten.aero.
